Turcon® Excluder® 500 is a heavy-duty, double-acting, O‑Ring-energized hydraulic scraper, also known as the Excluder 5,that provides excellent protection in large-bore, mobile, and off‑highway hydraulic systems. By integrating dual-action scraping and oil retention in a robust PTFE composite, the Excluder® 500 ensures maximal protection and long service life in large-scale hydraulic systems operating under extreme conditions.
Scrape/ Excluder®Turcon®:
Groove Diameter Outside68.8 mm
Signature StandardWEP100600-Z05N
Quality (10th Digit)-
TSS Article Number (3 to 9)P100600
Type of Article0
Root Groove Inside Diameter60 mm
Groove Diameter Inside60 mm
Root Groove Outside Diameter68.8 mm
Root Groove Thickness6.3 mm
Article GroupWE
Groove Thickness4.4 mm
Groove Width6.3 mm
Compound codeZ05N
Material Information for the product(s) on this page
Z05
Z05 Engineering Data Sheet_Ed1_rev0
Gravity Unit:
g/cm³
Minimum Temperature:
-30
Hardness Tolerance:
+/- 3
Minimum Hardness:
97
Shore A Hardness:
97+/- 3
Material:
Z05
Material Type:
PUR
Gravity Tolerance:
+/-0.03
Maximum Hardness:
97
Material Code Class:
Thermoplastic
Hardness unit:
Shore A
Specific Gravity:
1.2
Maximum Temperature:
80
Color:
Turquoise
