Turcon® Excluder® 2 is a compact, double-acting O‑Ring‑energized PTFE scraper engineered for hydraulic and pneumatic cylinders used in moderate to heavy-duty and helix-motion applications. The Excluder® 2 optimizes seal protection in compact hydraulic systems by combining efficient debris scraping and lubricant retention in a single, low-profile design, extending service life and reducing maintenance needs in demanding environments.
Scrape/ Excluder®Turcon®:
Groove Diameter Outside42.8 mm
Signature StandardWE3100360-T46N
Quality (10th Digit)-
TSS Article Number (3 to 9)3100360
Type of Article0
Root Groove Inside Diameter36 mm
Groove Diameter Inside36 mm
Root Groove Outside Diameter42.8 mm
Root Groove Thickness5 mm
Article GroupWE
Groove Thickness0 mm
Groove Width5 mm
Compound codeT46N
Material Information for the product(s) on this page
N7083
Specific Gravity:
1.24
Shore A Hardness:
70+/- 5
Gravity Unit:
g/cm³
Hardness unit:
Shore A
Material:
N7083
Material Type:
NBR
Color:
Black
Minimum Temperature:
-30
Maximum Temperature:
100
Material Code Class:
Elastomer
Minimum Hardness:
70
Gravity Tolerance:
+/-0.02
Maximum Hardness:
70
Hardness Tolerance:
+/- 5
T46
Color:
Greyish to Dark Brown
Maximum Temperature:
260
Minimum Temperature:
-200
Ball Hardness:
29
Gravity Tolerance:
+/-0.04
Material:
T46
Material Code Class:
Thermoplastic
Specific Gravity:
3.07
Material Type:
PTFE
Gravity Unit:
g/cm³
