WSW000800-Z201

The Trelleborg Zurcon® Scraper ASW has an additional supporting bead on the inner surface which prevents twisting of the scraper in the groove, also preventing impurities from reaching the back of the scraper. It efficiently removes dirt, dust and water while leaving the required residual oil film on the rod. Simple installation.

Scraper/ASW:

Groove Diameter Outside88 mm

Signature StandardWSW000800-Z201

Quality (10th Digit)-

TSS Article Number (3 to 9)W000800

Type of Article0

Root Groove Inside Diameter80 mm

Root Groove Outside Diameter88 mm

Root Groove Thickness4 mm

Groove Diameter Inside80 mm

Article GroupWS

Groove Thickness4 mm

Groove Width4 mm

Compound codeZ201

Instruction (PDF) 1

Material Information for the product(s) on this page

Z201

Material data sheet

Colour:

Turquoise

Basic Material:

PUR

Hardness:

92 (Shore A)

Commercial Description:

A proprietary polyurethane material specially developed by Trelleborg Sealing Solutions for the manufacture of sealing elements. It offers high wear resistance, low compression set, a wide operating temperature range, and almost universal media compatibility. This material is most often used in linear and static applications requiring high wear resistance and good sealability.
