SWP are polyurethane manufactured lipped wipers with integrated metal reinforcement for open groove assembly. These are typically used in severe applications where there is abrasion due to solid matter on rod surface.
Scraper/ASW:
Groove Diameter Outside60 mm
Signature StandardWSP000500-Z2022
Quality (10th Digit)-
TSS Article Number (3 to 9)P000500
Type of Article0
Root Groove Inside Diameter50 mm
Root Groove Outside Diameter60 mm
Root Groove Thickness5 mm
Root Groove Width4 mm
Groove Diameter Inside50 mm
Article GroupWS
Groove Thickness5 mm
Groove Width4 mm
Compound codeZ2022
Material Information for the product(s) on this page
Z2022
Colour:
Turquoise
Basic Material:
PUR/metal
Hardness:
92 (Shore A)
