The Trelleborg Turcon® Glyd Ring® T is a double-acting O-Ring energized rod seal for dynamic applications, offering low friction with no stick-slip, minimal break out force and high wear resistance. The trapezoidal cross-section of the Turcon® Glyd Ring® T provides very good static leak-tightness and the angles of each lip are designed to provide improved leakage control and better resistance to extrusion.
Rod/GlydRing®T/ Turcon®:
Groove Diameter Outside25.30000000000000 mm
Signature StandardRT0100180-M12N
Quality (10th Digit)-
TSS Article Number (3 to 9)0100180
Type of Article0
Groove Diameter Inside18 mm
Root Groove Inside Diameter18 mm
Root Groove Outside Diameter25.30000000000000 mm
Root Groove Width3.200000000000000 mm
Article GroupRT
Groove Width3.200000000000000 mm
Compound codeM12N
Material Information for the product(s) on this page
M12
Colour:
Dark Grey
Basic Material:
PTFE
Filler:
Virgin PTFE compounded with Turcon®, mineral fibre and additives
Commercial Description:
Turcon® M12 is a modern compound and the new standard industrial material. A development of thorough benchmarking and performance testing, Turcon® M12 offers low friction, high wear resistance and costs on par with standard bronze-filled compounds. This material is designed to be the first choice for seals used with linear motion, replacing standard (medium-filled) industrial bronze-filled compounds. Used in article numbers ending in M12N and M12V.
N7
Colour:
Black
Basic Material:
NBR
Commercial Description:
A 70 durometer, NBR elastomer. The properties of the nitrile rubber depend mainly on the ACN content which ranges between 18 % and 50 %. In general it has good mechanical properties with an operating temperature range of between -30 °C and +100 °C. NBR is mostly used with mineral based oils and greases and is a good choice for standard applications. Used also as an energizer in T46N, M12N, Z20N, and Z52N.
