A single-acting Trelleborg O-Ring energized rod seal with hydrostatic ventilation for use in dynamic applications. Prevents pressure build-up between seals in all service conditions. Low friction with no stick-slip, minimal break out force and high wear resistance. Recommended for use with a secondary rod seal in Turcon® material, together with a double-acting Excluder® or Scraper.
Material Information for the product(s) on this page
V7
Colour:
Green
Basic Material:
FKM
Commercial Description:
A 70 durometer FKM. FKM is an elastomer material known especially for its non-flammability, low gas permeability and excellent resistance to ozone, weathering, and ageing. The operating temperatures of the fluorocarbon rubber range between -20 °C and +200 °C (for a short period of time up to +230 °C). FKM is also often used with mineral based oils and greases at high temperatures. Used as an energizer in T46V and M12V
M12
Colour:
Dark Grey
Basic Material:
PTFE
Filler:
Virgin PTFE compounded with Turcon®, mineral fibre and additives
Commercial Description:
Turcon® M12 is a modern compound and the new standard industrial material. A development of thorough benchmarking and performance testing, Turcon® M12 offers low friction, high wear resistance and costs on par with standard bronze-filled compounds. This material is designed to be the first choice for seals used with linear motion, replacing standard (medium-filled) industrial bronze-filled compounds. Used in article numbers ending in M12N and M12V.
